Speedy Shaft Drive Transmission Cable Winch Puller With Gasoline Honda GX390 13HP Engine

Speedy Shaft Drive Transmission Cable Winch Puller With Gasoline Honda GX390 13HP Engine
Speedy Shaft Drive Transmission Cable Winch Puller With Gasoline Honda GX390 13HP Engine Speedy Shaft Drive Transmission Cable Winch Puller With Gasoline Honda GX390 13HP Engine

Large Image :  Speedy Shaft Drive Transmission Cable Winch Puller With Gasoline Honda GX390 13HP Engine

Product Details:
Place of Origin: Ningbo China
Brand Name: Linkai
Certification: ISO
Model Number: JJM-5B
Payment & Shipping Terms:
Minimum Order Quantity: 1set
Price: get the latest
Packaging Details: wooden case
Delivery Time: 3-5work days
Payment Terms: T/T, L/C, Western Union
Supply Ability: 100sets/day
Detailed Product Description
Model: JJM-5B Engine: Honda GX390 13HP
Power: 5T Feature: Fast Speed
Type: Shaft Driven Approval: ISO
High Light:

portable capstan winch

,

gas powered winch

5 Ton Speedy Shaft Drive Transmission Gasoline Engine Winch with Honda GX390 13HP



Application

Gasoline engine powered winch referred to as gasoline winch, mainly used for erecting air high-voltage transmission lines and the laying of underground cables, gasoline engine powered winch automatic clamp brake and clutch transmission chain brake two kind of braking device, in the opposite direction are positive, the braking action.

Gasoline Winch can be modified as per requirement, such as changing curve capstan into straight even cylindrical shape and coming with steel rope.



Features

1) Speedy and Efficient

2) Safe and Reliable

3) Compact structure

4) Widely used

5) Light weight



Technical Data for 5 Ton Speedy Gasoline Engine Winch

Model Type Gear Pulling Force(KN) Pulling Speed(m/min) Power(KW) Dimension(mm) Weight(kg)
JJM-5B HONDA gasoline engine GX390 13HP Fast 9 24 10 1100*498*600 137
Mid 15 14
Mid 30 9
Slow 50 5
